Máquina para biselar formas de vidrio

MAIN SPECIFICATION

◆ Diámetro móvil: 100-2000 mm

◆ Espesor del vidrio: 3-30 mm

◆ Ancho máximo de bisel: 35mm

◆ Ángulos de bisel: 0-15 grados

◆ Velocidad de rotación: 0,5-2,5 rpm

◆ Área de ocupación: 2500x 2500mm

◆ Potencia total: 5KW (380 V/50 Hz)

◆ Peso: 1000kilogramo

◆ Tamaño total: 2500x 2500x2000mm

Una variedad de tamaños pueden satisfacer las diferentes necesidades de procesamiento de los clientes, contáctenos para obtener más detalles.

consulta

Escribe una reseña

معلومات المنتج

SKD-01 Glass Irregular Shape Edging Machine is suitable for the peripheral grinding of special-shaped beveled edge, round edge, flat edge and duck edge of various flat glass. Glass decoration work on-site construction, When processing different sizes of glass, the installation and adjustment work is convenient and quick.

There are five sets of suction cups on the worktable of the Glass Irregular Shape Edging Machine, which firmly adsorb the glass on the table. One end of the rotating arm does not rotate around the main shaft, and the other end is connected with the rocker arm. Reach the required position for processing.

Specification Drawing

图片3 (5)

玻璃异型磨边机(SKS-01) (1)

微信图片_20220324112543

图片1 (7)

Advantage

Glass Irregular Shape Edging Machine can process special-shaped glass products with beveled edge, round edge, flat edge, OG edge and other shapes by replacing grinding wheels with different functions.

Máquina para biselar formas de vidrio 10

Glass Irregular Shape Edging Machine is easy to operate and has a wide range of processing, making it an ideal processing machine.

Máquina para biselar formas de vidrio 11

The base is made of castings, and the rest of the parts are made of high-strength cast iron, so the machine has high strength, high precision and stable performance.

Máquina para biselar formas de vidrio 12

The Glass Irregular Shape Edging Machine can move on the irregular edge of flat glass with diameter from 100 to 2200mm. And the speed can be adjusted arbitrarily.

The Glass Irregular Shape Edging Machine has low power consumption, light weight, small volume, high production efficiency and convenient use.

APPLICATION

Widely used in the deep processing of glass exterior walls, glass doors and windows, shower rooms, glass partitions, glass fences, automotive glass, furniture glass, and mirror frame glass.

FAQ

About voltaje

Voltage can be customized

GUARANTEE / WARRANTY

The quality guarantee period for one year, any damages on the electric parts during the quality gaurantee period can be maintained or replaced free, (Except in the course of usage, damage due to human errors), and after guarantee period, SANKEN will continuously give good support and best after-sales service to customer.

About delivery time

30 WORKING DAYS AFTER RECEIVING 30% ADVANCE PAYMENT.

About payment terms

30% SHALL BE PAID BY T/T AS DOWN PAYMENT IN ADVANCE;
70% BALANCE SHALL BE PAID OFF BY T/T BEFORE SHIPMENT.
